Overview
When it comes to high-rise construction, infrastructure renovation, or industrial material handling, a reliable and high-capacity lifting tool is non-negotiable. Our big cage electric powered construction lift with CE certification stands out as a top-tier choice for contractors and project managers seeking efficiency, safety, and compliance. Designed to meet the rigorous demands of heavy-duty construction sites, this lift combines robust engineering with user-centric features to streamline vertical transportation workflows.
Core Advantages of Our Big Cage Electric Construction Lift
High Load Capacity & Lifting Height
Equipped with a high-power electric motor and reinforced steel structure, our electric powered construction lift offers an impressive payload capacity of up to 2000kg, making it ideal for transporting construction materials, tools, and personnel simultaneously. The lift supports a maximum lifting height of 300m, perfectly matching the needs of high-rise residential buildings, commercial skyscrapers, and large-scale industrial facilities. Unlike hydraulic lifts, the electric drive system ensures stable and smooth operation with minimal noise, reducing disturbance to on-site workers and surrounding environments.
CE Certification & Full Compliance with International Standards
As a CE certified construction lift, our product has passed strict testing for structural integrity, safety performance, and environmental protection. The certification not only ensures compliance with EU market requirements but also reflects our commitment to quality and reliability. For global construction projects, this certification eliminates trade barriers and provides clients with the confidence that they are investing in a product that meets the highest industry benchmarks.
Advanced Safety System of Big Cage Construction Lift
Overload Protection & Emergency Stop Functions
The built-in overload protective device automatically detects excessive weight and triggers an alarm to stop the lift from operating, avoiding structural damage and safety hazards caused by overloading. Additionally, the lift is fitted with emergency stop buttons at both the cage interior and ground control panel, allowing workers to halt the lift instantly in case of emergencies.
Limit Switches & Anti-Fall Mechanism
Top and bottom limit switches precisely control the lift’s travel range, preventing over-travel that could lead to collisions or derailment. The advanced anti-fall mechanism acts as a last line of defense, locking the lift in place immediately if any abnormal movement or power failure is detected, ensuring the safety of personnel and materials inside the cage.
Technical Specifications of Electric Powered Construction Lift
Parameter | Specification |
Drive Type | Electric |
Maximum Payload | 2000kg |
Maximum Lifting Height | 300m |
Lifting Speed | 0-36m/min (adjustable) |
Cage Size | Customizable according to client needs |
Certification | CE, ISO 9001 |
Characteristic | Model | Rated Loading | Lifting Speed | Motor Power | |
Double cages | SC200/200 | 2x2000kg | 33m/min | 2x(3x11kw) / 2x(3x8.5kw) | |
SC150/150 | 2x1500kg | 33m/min | 2x(2x13kw) | ||
SC100/100 | 2x1000kg | 33m/min | 2x(2x11kw) | ||
Single cage | SC200 | 2000kg | 33m/min | 3x11kw /3x8.5kw | |
SC150 | 1500kg | 33m/min | 2x13kw | ||
SC100 | 1000kg | 33m/min | 2x11kw | ||
Double cages | Low speed | SC200/200D | 2X2000kg | 0-40m/min | 2x(3x11kw)/2x(3x8.5kw) |
SC100/100D | 2x1000kg | 0-40m/min | 2x(2x13kw) | ||
Mid speed | SC200/200Z | 2x2000kg | 0-60m/min | 2x(2x23kw) | |
SC100/100Z | 2x1000kg | 0-60m/min | 2x(2x15kw) | ||
Single cage | Low speed | SC200 | 2000kg | 0-40m/min | 3x11kw /3x8.5kw |
SC100 | 1000kg | 0-40m/min | 2x13kw | ||
Mid speed | SC200 | 2000kg | 0-60m/min | 2x23kw | |
SC100 | 1000kg | 0-60m/min | 2x15kw | ||
Item | Construction hoist |
Model | SC100/100/SC200/200 |
Rated capacity/per cage | 1000kg-2000kg |
Lifting speed | 0-63m/min,0-42m/min,0-33m/min |
Cage size | 3.2*1.5*2.4m |
Motor power | 3*15kw/3*11/2*15/3*18.5 |
Speed ratio | 1:18 /1:16 |
Invertor Power | 45 kW/37kw |
Safety device | SAJ40-1.2/SAJ40-1.4/SAJ30-1.2 |
Mast section size | 0.65*0.65*1.508m |
Max. Installation height | 300m |
Cable type | Cable basket/cable trolley |
Why Choose Our CE Certified Big Cage Construction Lift?
Beyond superior performance and safety, we offer comprehensive services to support our clients throughout the project lifecycle. As a professional construction lift manufacturer, we provide customized solutions, including cage size customization and lifting height adjustment, to meet the unique needs of different projects. Our after-sales team offers on-site installation guidance, maintenance training, and timely spare parts supply, ensuring that the lift maintains optimal performance for long-term use.
For contractors looking to enhance construction efficiency and ensure on-site safety, our big cage electric powered construction lift with CE certification is the perfect investment. Contact us today to get a detailed quote and discuss how our lift can be integrated into your next construction project. Let us help you elevate your construction efficiency to new heights!
FAQ About Our CE Certified Big Cage Electric Construction Lift
Is the big cage electric construction lift suitable for outdoor construction sites?
Yes. Our CE certified construction lift is designed with a weather-resistant steel structure and sealed electrical components, making it suitable for outdoor use in various climates. It can withstand moderate rain, dust, and temperature fluctuations, ensuring stable operation on open construction sites.
How long does the installation of this electric powered lift take?
The installation duration typically ranges from 3 to 5 days, depending on the lifting height and on-site conditions. Our professional team provides on-site installation guidance and debugging services to ensure the big cage construction lift is installed correctly and meets safety standards before use.
What maintenance is required for the lift to ensure long-term performance?
Regular maintenance includes checking theoverload protective device, limit switches, and anti-fall mechanism monthly, lubricating moving parts quarterly, and conducting annual comprehensive inspections. We offer maintenance training and timely spare parts supply to help you keep the lift in optimal condition.
Can the cage size be customized beyond standard specifications?
Absolutely. We provide flexible customization services for the cage size of our electric powered construction lift to adapt to specific material transportation needs or site space constraints. You can discuss your requirements with our team to get a tailored solution that matches your project demands.
Does the lift come with a warranty?
Yes. We offer a 1-year warranty on the main components of the big cage electric powered construction lift, including the motor, safety system, and steel structure. Our after-sales team is available 24/7 to address any issues during the warranty period and provide efficient maintenance support.
