100Robust design and excellent comfort
• A high-efficiency helical gearbox provides lower power consumption and reduced operational costs
• Single and dual cage configurations
• Compatibility with Alimak Scando 650 accessories *
• Easy to use stop-next-landing control system, based on proven Alimak technology
• Built-in electrical cabinet maximises internal hoist dimensions for increased lifting capacity
• Durable materials: high quality steel for increased strength and weight reduction. Cage walls and door cladding of perforated steel sheeting, with hot dip galvanized steel mast sections
• Light in cage for maximum usability and operator comfort
• Optional installation crane
|
Characteristic |
Model |
Rated Loading |
Lifting Speed |
Motor Power |
|
|
Double cages |
SC200/200 |
2x2000kg |
33m/min |
2x(3x11kw) / 2x(3x8.5kw) |
|
|
SC150/150 |
2x1500kg |
33m/min |
2x(2x13kw) |
||
|
SC100/100 |
2x1000kg |
33m/min |
2x(2x11kw) |
||
|
Single cage |
SC200 |
2000kg |
33m/min |
3x11kw /3x8.5kw |
|
|
SC150 |
1500kg |
33m/min |
2x13kw |
||
|
SC100 |
1000kg |
33m/min |
2x11kw |
||
|
Double cages |
Low speed |
SC200/200D |
2X2000kg |
0-40m/min |
2x(3x11kw)/2x(3x8.5kw) |
|
SC100/100D |
2x1000kg |
0-40m/min |
2x(2x13kw) |
||
|
Mid speed |
SC200/200Z |
2x2000kg |
0-60m/min |
2x(2x23kw) |
|
|
SC100/100Z |
2x1000kg |
0-60m/min |
2x(2x15kw) |
||
|
Single cage |
Low speed |
SC200 |
2000kg |
0-40m/min |
3x11kw /3x8.5kw |
|
SC100 |
1000kg |
0-40m/min |
2x13kw |
||
|
Mid speed |
SC200 |
2000kg |
0-60m/min |
2x23kw |
|
|
SC100 |
1000kg |
0-60m/min |
2x15kw |
||
|
Item |
|
|
Model |
SC100/100/SC200/200 |
|
Rated capacity/per cage |
1000kg-2000kg |
|
Lifting speed |
0-63m/min,0-42m/min,0-33m/min |
|
Cage size |
3.2*1.5*2.4m |
|
Motor power |
3*15kw/3*11/2*15/3*18.5 |
|
Speed ratio |
1:18 /1:16 |
|
Invertor Power |
45 kW/37kw |
|
Safety device |
SAJ40-1.2/SAJ40-1.4/SAJ30-1.2 |
|
Mast section size |
0.65*0.65*1.508m |
|
Max. Installation height |
300m |
|
Cable type |
Cable basket/cable trolley |
Our company abides by the business philosophy of "quality first, customer first" to ensure product quality. We have rigorous production procedures, and each production process is carried out under strict quality inspection.Only after passing the inspection can they move on to the next procedure. At the same time, we insist on creating a neat, clean and safe working environment.
Completed safety measures Of Construction Hoist
1. Equiping with Anti-falling govenor
2. Electrical an Mechanical interlock: Door safety switches, Slack rope switch
3. Safety hook
4. Upper and bottom limit swithes, trap door limit switch
5. Overload protector
6. Bottom Buffer
7. Frequecy Conversion (Inverter) can be choose
8. PLC Control system can be choose
9. Level Calling system and Auto leveling device to be choose.
On large projects, clients benefit from our input at pre-planning stage to help determine exact lifting requirements. With our comprehensive service, we can advise clients on the most suitable access solution as well as providing the desired level of design input at any stage of the process.
We pay all our attention for CE approved Materials Passenger hoist Building Construction Hoist design and manufacturing.
